GALAXY 1.0 250 HG
IMPORTANT: Storage tier plates shown in the pictures are sold separately.
+++++++++++++++++++++
The GALAXY is a Powerhouse in a compact package !
- Commercial Grade steel to endure the toughest demands : 75*75 mm tubing with 3 mm thickness
- Functional Trainer with adjustable trolley
- Storage options for everything you need
- 9 sqm is all you need to install the Galaxy
The Galaxy 250 HG package includes :
- Galaxy Half Rack with 2*250 lbs / 112.5 kg stack (upgrade to 300 lbs / 135 kg available)
- 2:1 ratio for the pulleys
- Aluminium pulleys for smooth operation and optimal range of motion
- Spotter Arms V2
- 4 Chrome Plates Holders
- Multi-Grip Pull Up Bar
- 1 pair of Blacksmith handles
Unlimited Customization : Compatible with all our line of STD75 rigs and racks, storage solutions and attachments, the Galaxy will evolve with you.
PERFECT FOR SMALL SPACE, PRIVATE GYM STUDIOS and HOME GYM / GARAGE GYM
STANDARD COLOR* IN PURE BLACK
*Other colors available (on request only): Light Gray , White; Deep Blue; Orange; Green, Gold etc. Please contact Us to discuss about your custom color rack.
TECHNICAL SPECIFICATIONS
Dimensions H243*W194*D173cm (with Plate Holders and Spotter Arms)
- Tubes: 75*75*3mm Pro Grade steel
- Aluminium Pulleys + Solid 25mm Steel Guide rods for smooth operation
- Cable-Pulley Ratio: 2:1 = the weight is divided by 2 (this ensure smooth operation). i.e - 100 kg = 50 kg
- Reinforced 2.5 mm Steel cable with max load to 500 kg per side
- Max Load (Power Rack): 600 kg / 1320 Lbs
- Max Load (Safety Spotter Arms): 300 kg / 660 Lbs
- Max Load (Multi-Grip Bar): 300 kg / 660 Lbs
- Minimum Floor Space Requirements: 9 sqm
- Gross Weight: 501 kg
- Net Weight: 460 kg
- Shipping in Wooden Box + Individual packaging for uprights
COMPATIBILITY AND OPTIONAL ATTACHMENTS
All our STD75 line is compatible with the Cosmos rack. This means you can custom and expand according to your needs:
- Galaxy Removable Seat
- Galaxy Low Row foot plate
- STD75 Jammer Arms
- STD75 Dip Bar
- STD75 Vertical Bar Holder / Landmine Sleeve
- STD75 Rig Shackles
- Mag Grips Set
- Pulley Grips Attachment
- Pull Up Bar with Rotating + Adjustable Handles
- STD75 Wall Ball Target
- STD75 Battlerope Anchor
- STD75 Plate Holders
- STD75 Storage tiers for Kettlebells, Bumpers, Dumbbells and Wall Balls
- STD75 X-beams
- STD75 Pull Up bar
- Galaxy Side Covers with Galaxy Logo
WARRANTY*
- Lifetime on steel frame and steel storage
- 3 Years on Spotter Arms
- 2 years on Cables and Pulleys
- 2 Years on removable attachments
- 1 Year on upholstery and linings
- 1 Year on grip attachments
*Warranty doesn't cover normal wear and tear and is only limited to regular use (void in case of alterations to the products and/or use of additional weights above the max load capacity)
